Jackson Adrian Smith Transparent Green X Series SDXQM

Jackson Adrian Smith Transparent Green X Series SDXQM

Regular price $649.99 USD
Regular price Sale price $649.99 USD
Sale Sold out

Iron Maiden is one of the most successful and influential metal bands ever, thanks to the molten yet melodic guitar work of Adrian Smith. With timeless songwriting and thrilling live performances, Maiden continues to record, tour internationally and rock stadiums everywhere with electricity.

Jackson honors Smith's metal prowess with the X Series Signature Adrian Smith SDXQM, featuring a poplar San Dimas® body with elegant quilt maple top, bolt-on maple neck with graphite reinforcement and a 12"-16" compound radius maple fingerboard with 22 jumbo frets, black dot inlays and licensed Fender® Strat® headstock.

The SDXQM also offers an HSS pickup configuration and is powered by a Jackson high-output humbucking bridge pickup, Jackson single-coil middle pickup and single-coil neck pickup with five-way blade switching and master volume and tone controls. A non-recessed Floyd Rose® Special double-locking 2-point tremolo bridge will withstand all the abuse you throw at it, providing rock-solid stability and stable tuning.

Available in a Transparent Green finish with a white pickguard and black hardware, this beauty looks as sharp as it sounds.



BODY
  • BODY MATERIAL
    Poplar
  • BODY FINISH
    Gloss
  • BODY SHAPE
    San Dimas®
NECK
  • NUMBER OF STRINGS
    6
  • NECK MATERIAL
    Maple
  • NECK CONSTRUCTION
    Bolt-On with Graphite Reinforcement
  • NECK FINISH
    Satin
  • SCALE LENGTH
    25.5" (64.77 cm)
  • FINGERBOARD MATERIAL
    Maple
  • FINGERBOARD RADIUS
    12"-16" Compound Radius (304.8 mm to 406.4 mm)
  • NUMBER OF FRETS
    22
  • FRET SIZE
    Jumbo
  • NUT MATERIAL
    Floyd Rose® Locking
  • NUT WIDTH
    1.6875" (42.86 mm)
  • POSITION INLAYS
    Black Dot
  • TRUSS ROD
    Dual-Action
  • TRUSS ROD NUT
    Vintage-Style Butt Adjust
ELECTRONICS
  • BRIDGE PICKUP
    Jackson® High-Output Humbucking
  • MIDDLE PICKUP
    Jackson® Single-Coil
  • NECK PICKUP
    Jackson® Single-Coil
  • CONTROLS
    Volume, Tone
  • SWITCHING
    5-Position Blade: Position 1. Bridge Pickup, Position 2. Bridge and Middle Pickup, Position 3. Middle Pickup, Position 4. Middle and Neck Pickup, Position 5. Neck Pickup
  • CONFIGURATION
    HSS
HARDWARE
  • BRIDGE
    Floyd Rose® Special Double-Locking Tremolo
  • HARDWARE FINISH
    Black
  • TUNING MACHINES
    Jackson® Sealed Die-Cast
  • PICKGUARD
    1-Ply White
  • CONTROL KNOBS
    Dome-Style
  • NECK PLATE
    Jackson®
12"-16" COMPOUND RADIUS FINGERBOARD

Jackson pioneered the use of the innovative 12"-16" compound radius design, in which the fingerboard gradually flattens toward the heel from its more rounded profile at the nut. This makes for comfortable and natural-feeling chording and riffing near the nut, with optimal shred articulation and bending nearer the heel.

12"-16" Compound Radius Fingerboard
MISCELLANEOUS
  • STRINGS
    Nickel Plated Steel (.009-.042 Gauges)
